RM0008

13.4.15

Advanced-control timers (TIM1&TIM8)

TIM1&TIM8 capture/compare register 2 (TIMx_CCR2)

Address offset: 0x38

Reset value: 0x0000

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

CCR2[15:0]

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

Bits 15:0 CCR2[15:0] : Capture/Compare 2 value

If channel CC2 is configured as output :

CCR2 is the value to be loaded in the actual capture/compare 2 register (preload value).

It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register (bit

OC2PE). Else the preload value is copied in the active capture/compare 2 register when an

update event occurs.

The active capture/compare register contains the value to be compared to the counter

TIMx_CNT and signalled on OC2 output.

If channel CC2 is configured as input :

CCR2 is the counter value transferred by the last input capture 2 event (IC2).

13.4.16

TIM1&TIM8 capture/compare register 3 (TIMx_CCR3)

Address offset: 0x3C

Reset value: 0x0000

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

CCR3[15:0]

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

Bits 15:0 CCR3[15:0] : Capture/Compare value

If channel CC3 is configured as output :

CCR3 is the value to be loaded in the actual capture/compare 3 register (preload value).

It is loaded permanently if the preload feature is not selected in the TIMx_CCMR3 register (bit

OC3PE). Else the preload value is copied in the active capture/compare 3 register when an

update event occurs.

The active capture/compare register contains the value to be compared to the counter

TIMx_CNT and signalled on OC3 output.

If channel CC3 is configured as input :

CCR3 is the counter value transferred by the last input capture 3 event (IC3).

Doc ID 13902 Rev 9

313/995
